Good Quality 12V Battery Pack - A grade rechargeable, long cycle life lithium battery cell – Teda
Good Quality 12V Battery Pack - A grade rechargeable, long cycle life lithium battery cell – Teda Detail:
Lithium Iron Phosphate(LiFePO4) Cylindrical Cell List
| Model | 26650-2500mAh | 26650-3000mAh | 26650-3300mAh | 26650-3600mAh | 26650-3800mAh | 26650-4000mAh | |
| Capacity(Ah)@0.2C | 2.5 | 3 | 3.3 | 3.6 | 3.8 | 4 | |
| Nominal Voltage (V) | 3.2 | 3.2 | 3.2 | 3.2 | 3.2 | 3.2 | |
| Energy Density | 103Wh/Kg | 110Wh/Kg | 123Wh/Kg | 123Wh/Kg | 123Wh/Kg | 130Wh/Kg | |
| Discharge | Standard | 0.5C | 0.5C | 0.5 | 0.5C | 0.5C | 0.5C |
| Max. | 50C | 15C | 8C | 5C | 3C | 3C | |
| Charge | Standard | 0.5C | 0.5C | 0.5C | 0.5C | 0.5C | 0.5C |
| Max. | 2C | 2C | 2C | 2C | 2C | 2C | |
| Temperature | Charge | 0~45°C | 0~45°C | 0~45°C | 0~45°C | 0~45°C | 0~45°C |
| Discharge | ‘-20~60°C | ‘-20~60°C | ‘-20~60°C | ‘-20~60°C | ‘-20~60°C | ‘-20~60°C | |
| Cycle life ( to 80% Cap.) | ≥2000cycles | ≥2000cycles | ≥2000cycles | ≥2000cycles | ≥1500cycles | ≥1300cycles | |
| Application | Energy Storage System, E-mobility, Solar Application, UPS, Motorcycle Starting, etc. | ||||||
Hot Sales Prismatic Cell List
| Model | LFP3.2V40Ah | LFP3.2V50Ah | LFP3.2V72Ah | LFP3.2V100Ah | LFP3.2V200Ah | LFP3.2V275Ah | |
| Nominal Capacity(Ah)@0.2C | 40 | 50 | 72 | 100 | 200 | 275 | |
| Nominal Voltage (V) | 3.2 | 3.2 | 3.2 | 3.2 | 3.2 | 3.2 | |
| Dimension (mm) | 148*27*97 | 148*27*129 | 222*29*135 | 173*47*133 | 173*53*207 | 173*71*207 | |
| Internal Resistance (mΩ） | 1 | 1 | 0.6 | 0.6 | 0.2 | 0.4 | |
| Weight (Kg) | 0.86 | 0.86 | 1.5 | 1.8 | 4.1 | 5.2 | |
| Discharge | Continuous | 1C | 1C | 1C | 1C | 1C | 1C |
| Pulse (10S) | 3C | 3C | 3C | 2C | 2C | 2C | |
| Charge | Max. | 1C | 1C | 1C | 1C | 1C | 1C |
| End Voltage(V) | 3.6 | 3.6 | 3.6 | 3.6 | 3.6 | 3.6 | |
| Temperature | Charge | 0~45°C | 0~45°C | 0~45°C | 0~45°C | 0~45°C | 0~45°C |
| Discharge | ‘-20~60°C | ‘-20~60°C | ‘-20~60°C | ‘-20~60°C | ‘-20~60°C | ‘-20~60°C | |
| Cycle life | ≥4000cycles | ≥4000cycles | ≥4000cycles | ≥4000cycles | ≥4000cycles | ≥4000cycles | |
| Application | Energy Storagy System, Electric car, Truck, Marine application, etc. | ||||||
Features
-Long cycle life
-High capacity
-High reliability
-High consistency
-Low self-discharge
-High energy density
-High safety performance
-With UL1642, IEC62133,UN38.3 approved.
Application
Mainly used on energy storage system, E-mobility, Solar battery, Medical product, AGV, SLA replacement battery, etc.
Product detail pictures:
Related Product Guide:
Our target should be to consolidate and improve the high-quality and repair of current goods, in the meantime regularly produce new solutions to meet unique customers' needs for Good Quality 12V Battery Pack - A grade rechargeable, long cycle life lithium battery cell – Teda , The product will supply to all over the world, such as: Malta, Canberra, venezuela, We've got sufficient experience in producing products according to samples or drawings. We warmly welcome customers from home and abroad to visit our company, and to cooperate with us for a splendid future together.
By Victoria from Mongolia - 2017.05.02 18:28
The customer service staff is very patient and has a positive and progressive attitude to our interest, so that we can have a comprehensive understanding of the product and finally we reached an agreement, thanks!
By Carlos from Greenland - 2017.06.19 13:51
